Tool Holders / S-System Modular End Mills (SCREW Type Tools)
AEM90-AX1705-D25-M12-L43-Z02-H
AEM90-AX series · see all 5 sizes
Insert compatibility
This size is built for the insert designation AX.T 1705 (as listed in the catalogue data).
Specifications — AEM90-AX1705-D25-M12-L43-Z02-H
| Insert Code | Insert designation | AX.T 1705.. |
|---|---|---|
| Product Direction | Cutting direction (hand) | R |
| DC | Cutting diameter (mm) | 25 |
| DCON | Connection diameter (mm) | 12.5 |
| DCSFMS | Contact-face diameter, machine side (mm) | 21 |
| LF | Functional length (mm) | 43 |
| ZEFP | Effective cutting edges | 2 |
| APMX | Depth of cut, maximum (mm) | 14 |
| TDZ | Thread depth (mm) | M12 |
Dimensions in millimetres unless noted. Values are the manufacturer's published figures.
All 5 sizes in AEM90-AX
| Product code | Cutting direction (hand) | Cutting diameter (mm) | Connection diameter (mm) | Contact-face diameter, machine side (mm) |
|---|---|---|---|---|
| AEM90-AX1235-D16-M08-L30-Z02-H | R | 16 | 8.5 | 14.75 |
| AEM90-AX1235-D20-M10-L30-Z03-H | R | 20 | 10.5 | 18 |
| AEM90-AX1235-D25-M12-L35-Z04-H | R | 25 | 12.5 | 21 |
| AEM90-AX1705-D25-M12-L43-Z02-H | R | 25 | 12.5 | 21 |
| AEM90-AX1705-D32-M16-L43-Z02-H | R | 32 | 17 | 29 |
