Tool Holders / C-System External Turning Toolholders
CCLNR 2525 M1607C
CCLNR/L series · see all 6 sizes
Insert compatibility
This size is built for the insert designation CN.N 1607 (as listed in the catalogue data).
Specifications — CCLNR 2525 M1607C
| Insert Code | Insert designation | CN.N 1607.. |
|---|---|---|
| Product Direction | Cutting direction (hand) | R |
| LF | Functional length (mm) | 170 |
| WF | Functional width (mm) | 40 |
| HF=H | Functional height (mm) | 32 |
| B | Shank width (mm) | 32 |
Dimensions in millimetres unless noted. Values are the manufacturer's published figures.
